iMatrix-221 Cardiac and Myoblast Cell Culture Substrate

NP892-061 / NP892-062

Brand: iMatrix™ by Matrixome®

iMatrix-221 is a xeno-free, recombinant Laminin-221 E8 Fragment expressed in CHO-S cells. Laminins of the α2-isoform are commonly found in the basal lamina of striated muscle and the predominant form found in adult human heart tissue.


Note: prices shown do not include shipping and handling charges.

Product code Pack size The Americas   UK, Europe, Middle East, Africa
(USD)   UK (GBP) Europe (EUR)

NP892-061
NP892-062

175 μg × 2 tubes
175 μg × 6 tubes

$ 684.00
$ 1,708.00



£ 613.15
£ 1,532.88

€ 695.94
€ 1,739.86

  USA store
The Americas
Product code Pack size USD

NP892-061
NP892-062

175 μg × 2 tubes
175 μg × 6 tubes

$ 684.00
$ 1,708.00

USA store
UK, Europe, Middle East, Africa
Product code Pack size UK (GBP)

NP892-061
NP892-062

175 μg × 2 tubes
175 μg × 6 tubes

£ 613.15
£ 1,532.88

Europe (EUR)

NP892-061
NP892-062

175 μg × 2 tubes
175 μg × 6 tubes

€ 695.94
€ 1,739.86


imatrix-221-cardiac-and-myoblast-cell-culture-substrate-p338-204_medium

iMatrix-221's features make it an ideal matrix for some cell culture applications:

  • Xeno-free formulation / CHO-S cell bioproduction
  • Easy to use (liquid format)
  • E8-fragments retain integrin binding specificity and capacity, and display higher potency than natural Laminin-221

iMatrix-221 is a highly purified and refined product of human recombinant laminin-221 (E8 fragment) expressed by CHO-S cells. Laminin-221 is found predominantly in the basal lamina of striated muscle tissues. Expression deficiencies are implicated in muscular dystophy and cardiomyopathies.1

Laminins of the α-2 type are also a predomiant form found in the human adult heart tissue.2 Cultivation of iPSC-drived cardiomyocytes on iMatrix-221 has been demonstrated to maintain strong contractility in attached monolayer culture.3

Specifications

Product Name: iMatrix-221 Cardiac and Myoblast Cell Culture Substrate

Catalog Numbers:

  • NP892-061
  • NP892-062

Sizes:

  • NP892-061 — 2 × 175 µg
  • NP892-062 — 6 × 175 µg

Molecular Weight: 150 kDa

Purity: > 95 % pure

Formulation: Purified Laminin-221 E8 proteolytic fragment

Storage and Stability: Store at 4 °C and protect from light exposure. Stable for 2 years from manufacturing date.

Quality Control: Activity: Kd for integrin binding

Sterility: Sterile

Notice To Purchaser: REPROCELL is a licensed distributor of Matrixome cell culture substrates to the global market.

Recommended Usage: iMatrix-221 is suitable for use as a substrate for culture of various myoblast cell types, but most notably for cardiomyocytes.

Concentration: 500 µg/mL

Source: CHO-S cell expression

Manufacturer: Matrixome Corporation (Japan)

Documents

Safety Data Sheets:

Product Flyer:

References

  1. Oliviero P. et.al., Expression of laminin α2 chain during normal and pathological growth of myocardium in rat and human. Cardiovascular Research 46, 346-355 (2000).
  2. Ja K.P. Myu Mia et.al., PSC-derived human cardiac progenitor cells improve ventricular remodeling via angiogenesis and interstitial networking of infarcted myocardium. J Cell Mol Med 20(2), 323-332 (2016).
  3. Unpublished, Osaka University (2018).
  4. Miyazaki T. et al. Laminin E8 fragments support efficient adhesion and expansion of dissociated human pluripotent stem cells. Nature Communications 3: 1236 (2012).
  5. Taniguchi Y. et al., The C-terminal region of laminin β-chains modulates the integrin-binding affinities of laminins. J. Biol. Chem.284 (12): 7820-31 (2009).
  6. Ido H. et al., The requirement of the glutamic acid residue at the third position from the carboxyl termini of the laminin gamma-chains in integrin-binding by laminins. J. Biol. Chem. 282 (15): 11144-54 (2017).
